1. This is an LTE Cat 6 Raspberry Pi communication HAT with GNSS and up to 300Mbps (downlink) / 50Mbps (uplink) data rate. It is applicable for countries/regions including Europe, the Middle East, Africa, Asia-Pacific, Brazil... By connecting it to PC, Raspberry Pi or Jetson Nano host boards, it is easy to enable LTE-A high speed networking, cloud platform communication, SMS, and global GNSS positioning functions.
2. Multi-constellation high-accuracy GNSS positioning: GPS, GLONASS, BeiDou/Compass, Galileo, QZSS
3. Integrates extensive network protocols, with multi drivers and software support, compatible with different OS including Windows / Linux / Android
4. USB 3.1 port (USB 2.0 compatible) for connecting to PC, Raspberry Pi, or Jetson Nano host board to enable high speed LTE-A communication
5. Standard M.2 B KEY slot, compatible with different core modules: EM06-E, EM06-J, EM06-A series
6. Onboard PWR and RST control pin, enabled via DIP switch, for connecting to external IO to turn on/off or reset the module
7. Onboard USB-C connector, enabled via switch, for connecting standalone power supply for the module, allows more loads, stable amd flexible power supply
8. Onboard power supply on/off switch, reset button and LED indicator, easy to turn on/off the module or monitor the operating status
9. Reserved 4x SMA to IPEX antenna interfaces, with pre-soldered 2x connectors for easily using antennas, allows changing the SMA antenna position
10. High efficiency power supply circuit, up to 3A output current
Specifications
LTE CAT 6:
1. Region / Provider: EMEA / APAC (except Japan and CMCC) / Brazil
2. Module dimensions: 42.0 x 30.0 x 2.3 (mm)
Temperature range:
1. Operating temperature: -30 degree C ~ +70 degree C
2. Extension temperature: -40 degree C ~ +85 degree C
Frequency band
1. LTE-FDD: B1, B3, B5, B7, B8, B20, B28, B32 (receive only for B32)
2. LTE-TDD: B38, B40, B41
3. 2xCA:
- B1+B1, B5, B8, B20, B28;
- B3+B3, B5, B7, B8, B20, B28;
- B7+B5, B7, B8, B20, B28;
- B20+B32 (B32 is used for aux component carrier only), B38+B38, B40+B40, B41+B41
4. WCDMA: B1, B3, B5, B8
5. GNSS: GPS/GLONASS/BeiDou (Compass)/Galileo/QZSS
Data rate:
1. LTE-FDD: 300 Mbps (DL) / 50 Mbps (UL)
2. LTE-TDD: 226 Mbps (DL) / 28 Mbps (UL)
3. DC-HSPA+: 42 Mbps (DL) / 5.76 Mbps (UL)
4. WCDMA: 384 Kbps (DL) / 384 Kbps (UL)
Package List
1. M.2 TO 4G/5G HAT x 1
2. EM06-E x 1
3. Antenna 2pcs x 1
4. IPEX adapter cable 2pcs x 1
5. 2*20PIN pin header x 1
6. Passive GPS antenna x 1
7. Dual plug USB3.0 cable x 1
8. USB3.0 adapter x 1
9. USB2.0 adapter x 1
10. SMA protective cap 2pcs x 1
11. Screws pack x 1
