Features: 1. Real-time positioning: query position information and adjust positioning interval, and navigate to find personnel. 2. Historical track: View the movement track of any day within 90 days 3. Fence: GPS fence: Compare the GPS positioning data and judge whether there is an alarm for entering or leaving the fence. WIFI fence: Compare the WIFI hotspots and judge whether there is an alarm in or out of the fence. 4. Health: Calculate the amount of exercise, calorie consumption and exercise journey of people. Medicine reminder: Three different modes of medicine reminder settings: single; daily and customized; and you can record the voice of the reminder, etc. 5. Call: Dial the locator phone: two-way talk. Voice monitoring: ask the locator to call back the specified number and listen to the sounds around the wearer 6. Command setting: make relevant settings for the positioner, for example: The master number is used to receive alarm information SOS SOS phone alarm Fall Detection Sensitivity and Fall Alarm Settings Call Answering Modes: Mute, Auto and Key Answer Buzzer Sound Lookup: The locator will make a sound. It is convenient to find the target more quickly. SMS alarm switch Remote restart, shutdown or factory reset, etc. 7. Message list: Displays all alarm lists of the locator, including offline, low battery and entry and exit of the electronic fence, etc. 8. Reminder settings: Open all to receive an alarm push. Please be sure to enable the relevant push permissions in the app permissions of your phone
GPS: GPS: 1. Chip model: TD1030 2. GPS signal: L1, 1575.42MHz C/A code 3. Number of GPS channels: 72 channels 4. GPS chip receiving sensitivity: -163dBm, capture: -147dBm 5. GPS positioning accuracy: 5-15m 6. GPS Antenna: LDS/Ceramic Antenna 7. AGPS: Support 8. AGPS fast positioning time: 28 seconds for cold start 9. LBS positioning accuracy: 100-1000M (based on AMAP database) 10. WIFI: only support RX WiFi chip model: built-in WiFi standard: 802.11b\802.11g\802.11n WiFi positioning accuracy: 5-50M (according to AutoNavi or Google data)
parameter: 1. Battery capacity: 1000mAh 2. Average standby current: 5mA/h 3. Average operating current: 8mA/h (positioning once every ten minutes) 4. Operating temperature: -20 to 70 degrees Celsius 5. Working humidity: 5% to 95% non-solidifying 6. Waterproof grade: IP67 7. Memory capacity (RAM+ROM): RAM 128Mb+ built-in ROM 196Mb 8. Chip platform: RTOS ASR3603S 9. Main frequency: 832MHz 10. Architecture: Single-core ARM Cortex-R5 processor 11. Number of cores: single core 12. Supported formats: GSM\WCDMA\FDD-LTE 13. Frequency bands: FDD: B1 B2 B3 B5 B7 B8 B20 B28A WCDMA: B1\2\5\8 GSM: Band B2\3\5\8 14. Standby mode: single card NANO
