1. Interface: PCI-Express. 2. Antenna: 4x5dBi 0mni directional detachable antenna. 3. Standard: IEEE 802.11ac, IEEE 802.11a, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b. 4. Frequency: 5.180-5.240 GHz, 5.745-5.825 GHz / 2.4 GHz - 2.484 GHz. 5. Rate: 5GHz: 11ac: Up to 1300Mbps (dynamic), 2.4GHz: 11n: Up to 600Mbps (dynamic). 6. 5GHz receiving sensitivity: 11a 6Mbps: -85dBm. 11a 54Mbps: -68dBm. 11ac HT20: -59dBm. 11ac HT40: -54dBm. 11ac HT80: -51dBm. 7. 2.4GHz receiving sensitivity: 11b 11Mbps: -80dBm. 11g 54Mbps: -68dBm. 11n HT20: -64dBm. 11n HT40: -61dBm. 8. Transmit power: less than 20dBm (EIRP). 9. Wireless mode: Ad-Hoc / Infrastructure mode. 10. Security: Support 64/128 bit WEP, WPA-PSK / WPA2-PSK, 802.1x. 11. Modulation: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM. 12. Operating system support: Windows 10, Windows 8.1, Windows 8, Windows 7, Windows XP. 13. Working temperature: 0-40 degrees Celsius. 14. Storage temperature: -40-70 degrees Celsius. 15. Operating humidity: 10% to 90% does not condense. 16. Storage humidity: 5 to 90 percent does not condense.
Follow these steps to insert the adapter into your computer: 1. Turn off your computer and connect the power cord and other attached peripherals to your computer. 2. Remove the outer casing panel. Locate the available PCl-E slot and remove its slot cover. 3. Carefully insert the adapter into the PCl-E slot and secure it with the captive screws. 4. Replace the panel housing. 5. Install the antenna. 6. Reconnect the power cord and turn on the computer.
Verified Compatible
Guaranteed fit for your device. Wrong part? Full refund including shipping.
