1. The current size can be set for limiting the output current, constant current drive, battery charging 2. Comes with output anti-backflow function, no need to add anti-backflow diode when charging battery 3. After undervoltage protection, as long as the input voltage can be restored to start without re-power off, can be restored 4. Enlarge the heat sink and copper, high power rectifier diode 5. Usage: - As a general lift module with overcurrent protection ability to use - As a battery charger - As a high-power LED constant current driver module 6. Note: this module in more than 3A, 35W use, please strengthen the heat dissipation
Parameters: 1. Input voltage: 4.8-30V 2. Output voltage: 0.5-30V 3. Output current: can work stably at 3A for a long time, and can reach 4A under enhanced heat dissipation 4. Output power: 35W with natural heat dissipation, 60W with enhanced heat dissipation 5. Conversion efficiency: 88 percent or so 6. Short circuit protection: yes 7. Operating frequency: 180KHz 8. Size: 68 x 37 x 22mm, mounting hole diameter 3mm 9. Weight: 38.7g
